AUDIO & ALARM SYSTEMS
- Audio/cassette/CD system working normally, CD cartridge present (if equipped).
- Antenna is present and functions properly.
- Radio speakers do not rattle at high volume.
- Remote entry system works properly (if equipped).
- Theft-deterrent system works properly (if equipped).
BATTERY SYSTEM
- Battery in good condition, has proper cold cranking amps and reserve capacity.
- Battery proper size and secure
- Battery posts free of corrosion.
- Cables in good condition.
BRAKING SYSTEM
- Inspect brakes, calipers, lines and hoses.
- No excessive vibration during braking.
- ABS operates on "panic stop".
- Parking brake sets and holds vehicle.
- Brake pads/shoes must have minimum of 50% wear remaining.
- No excessive grooving or heat checking of rotors or drums.
- Parking brake releases completely.
- Brake pedal is free play and travel is normal.
EMISSIONS & STATE INSPECTION
- Perform emissions test and/or state inspection, if required.
ENGINE COMPARTMENT
- Change engine oil and filter.
- Check for evidence of sludge.
- Inspect for fuel, oil, coolant or other fluid leaks.
- Engine cold high idle correct.
- No abnormal engine noise at cold start
- Throttle does not stick shut on cold start.
- Drivability ok during warmup.
- Hot drivability ok.
- Engine reaches normal operating temperature.
- Engine fan functions properly.
- No excessive drone or vibration from engine.
- Drive belts and hoses free of cracks or damage.
- No damage to engine mounts.
- Check under-hood labels and decals.
- Engine compartment is clean.
- Under-hood heat insulator pad is clean.
- Engine free of excessive dressing.
- Inspect air filter.
- Oil, brake, clutch, transmission, transfer case, washer and power steering fluid levels ok.
- Under-hood fluids clear and uncontaminated.
ENGINE COOLANT & HVAC SYSTEM
- Engine coolant at proper hot and cold levels.
- Coolant specific gravity to -31 degrees.
- A/C cooling operation normal.
- A/C refrigerant sight glass clear.
- Heater operation normal.
EXTERIOR CONDITION & APPEARANCE
- Exterior is clean and free of residue.
- No cracked or broken lenses of exterior lights.
- Outside rearview mirror operates/lens is good.
- Glass free of cracks, stars and large chips.
- Glass is free of improper repairs.
- Bumpers are free of cuts, gouges and scratches.
- Body is reasonably free of dings.
- Paint is reasonably free of scratches and chips.
- Vehicle is free of improper paint repairs or mismatched color.
- Hood and trunk latches working.
- Free of water spots.
- Paint is free of swirl marks.
- Paint has even, high luster.
- Paint is free of buffable scratches.
- Free of wax residue.
- Wheelwells are clean.
- Acceptable aftermarket items checked.
- Removal of unacceptable aftermarket items.
FRAME, STRUCTURE & UNDERBODY
- Frame/Unibody check.
- Inspect body surface.
- Inspect panel alignment and fit.
- inspect lower body and underbody for damage.
- check exhaust systems and hangers.
HYBRID COMPONENTS
- Hybrid Vehicle Immobilizer System.
- Multi-Information Display.
- Inverter Coolant Level
- Engine and ECT (Electronically Controlled Transmission).
- ABS (Anti-lock Brake Systems)
- EMPS (Electric motor assisted power steering).
- CCS (Cruise Control system).
- SRS (Supplemental Restraint System).
- HV ECU (Hybrid Vehicle Electronic Control Unit).
- HV (Hybrid Vehicle) Battery.
- Perform "Onboard Equalizing Charge" of HV Battery using intelligent tester.
- Fully charge 12-Volt auxiliary battery.
- Clean or replace air refiner filter.
- Check park mechanism.
INSTRUMENT PANEL & ELECTRONIC SYSTEMS
- Master key is present.
- Fuel gauge reads correctly.
- Battery voltage gauge reads correctly.
- Horn works.
- Airbag deployment/replaced airbag.
- Speedometer and Odometer work properly.
- Cruise control operation normal.
- Clock keeps time.
- All wiper speeds work correctly.
- Windshield washer operates.
- Wiper blades are in good condition and work.
- Wipers return to correct position when off.
- All mirrors have a full range of adjustment.
- Windows operate normally.
- Window locks operate normally.
- Power windows operate from master switch and all door switches.
- Memory seat control operates properly.
| INTERIOR CONDITION & APPEARANCE
- Day/night mirror operates and lens is good.
- Window tinting clear and free of bubbles.
- Cigarette lighter is intact and operates.
- Ashtrays function and are in good condition.
- Ashtrays and lighter are clean; no evidence of use.
- Headliner, sun visors, dash pad, upholstery, console, cup holders,trim panels, floor mats and carpets are in good condition.
- Cup holder extends completely and sturdily.
- Doors open and close correctly.
- Seats, including child safety locks, work properly.
- Headrests function properly.
- Rear defogger grid lines intact.
- Interior leather, vinyl, plastic, carpet and fabric surfaces are free of holes, rips, tears, excessive wear or fading.
- No evidence of previous improper repairs.
- Inspect seatbelt conditions.
- seatbelts have full range of extension and smooth operation.
- Seatbelts lock up per specification.
- Inside remote release operates normally.
- Interior is free of debris.
- Dash and vents are clean and properly dressed.
- All crevices are clean.
- Doorjambs are clean.
- Glove box and console compartments are clean.
- Seats, carpets, floor mats and headliner are free of stains.
- Free of odor, including heavy perfume.
- Glass is clean and free of streaks.
LIGHTING SYSTEMS
- Warning lights function
- High and low beams ok.
- Headlight aim is ok.
- Tailights work.
- Brake lights work.
- Side marker lights work.
- Backup lights work.
- License plate lights work.
- Instrument lights work.
- Heater lights work.
- dash light dimmer works.
- Turn signal operate correctly and self-cancel.
- Four-way flashers work.
- Defogger indicator light turns on with switch on.
- Dome/courtesy lights operate with door cycles.
STEERING SYSTEM
- Steering has normal feel in lock-to-lock turning.
- Steering wheel centered in straight line driving.
- Vehicle tracks and drives straight on level surface.
- Tilt steering wheel adjustment works properly.
- No excessive wind whistle or buzz.
- No excessive tire vibration or steering wheel shimmy at any speed.
- Interior free of significant squeks or rattles.
- Inspect steering rack, linkage, bushings, control arms and dust boots.
TIRES AND SUSPENSION SYSTEM
- Inspect tires for defects, damage and inflation.
- Minimum of 5/32" tread depth remaining across tread width.
- All four tires must be of some brand, model, size, tread design, speed and load rating.
- Wheels are clean and free of brake dust.
- Tires are dressed, not greasy.
- Wheel cover caps secure with no damage.
- Inspect struts/shocks for leaks and wear.
- No damage to CV joints/boots.
TRANSMISSION/TRANSAXLE
- Transmission/clutch operates smoothly.
- Automatic transmission in ECT power mode shifts properly.
- Transmission gear ranges engage promptly while shifting when warmed up.
- Transmission does not shift into overdrive when button is in off position.
- Inspect transmission case and pan for leaks.
- No damage to drive and axle shafts.
- Differential fluid level correct.
TRUNK COMPARTMENT AND SPARE
- Trunk is clean, free of debris and no stains.
- Trunk light and trunk trim appearance.
- Jack and tools are correct, present and secured.
- Fiber board tire cover is not broken or warped.
- Spare tier is present.
- Spare tire and storage areas are clean.
- spare tire is securley fastened.
- No signs of damage to spare tire.
- Minimum 5/32" tread remaining on spare.
- spare tire has correct air pressure.
VEHICLE HISTORY
- Run and print a CARFAX Vehicle history report/Check for outstanding service campaigns.
ADDITIONAL ITEMS, WHERE APPLICABLE
- "Fade-away dome light works properly.
- Sunroof/convertible top operates normally through full range of positions.
- Convertible top lockout function operates.
- radio security codes cleared.
- Navigation system works properly.
- Transfer case smoothly switches from 2WD to 4WD and back from 4WD to 2WD.
- Truck bedliner is in good condition.
- tailgate functions properly.
- Rear bumper is in good condition and secured.
|
